PRODUCT / Central Vacuum Power Units / MUA63
MUA63
DA VINCI Quiet Allegro Central Vacuum
Allegro MUA63 Acoustic DaVinci is a heavy-duty unit that is ideal for primarily commercial application and for homes up to 10,000 sq. ft. (1000m2)
UPC: 609207104070
|
Allegro's Eco-Line Green Powered models are designed for high efficiency performance to save on electricity and are rated to have twice the life of regular blower motors. It saves money and the environment - Now that is eco-friendly! |
Motor: | Lamb powered, 2-Stage AMETEK® 6.6" single speed motor with tangential bypass and 10mm shaft and bearing system for extra structural rigidity. | |
| Air Watts: | 660 Air Watts of efficient cleaning power | |
| Air Flow: | Air-flow of 131.1 cubic foot per minute | |
| Suction Power: | Excellent Suction power of 140.8 inch H2O lift | |
| Max Amps: | Save on energy costs with a maximum current of 14.0 Amps | |
| Volts: | Compatible with standard ~110 - 120v service. | |
| Input Power | 1680 watts of powerful performance making cleaning that much easier! |
| Construction: | 14" width x 43" height with a 8 gallon dirt pail. Made of all steel construction. 41lbs. | |
| Filtration: | Self cleaning, no maintenance, patented Fibro-Tex Filtration Systems. This permanent filtration system never needs to be replaced or washed. | |
| Finish: | Primed with environmentally friendly electrostatic powder coat. Guaranteed for life against corrosion perferation. |
Acoustic Unit Technical Specifications
Technical characteristics
| Main parameters | Model - MUA63 |
|---|---|
| Cleaning Area | 10,000 sq. foot |
| Suction Power | 131.5 inch water lift |
| Air-Flow | 138.8 CFM |
| Air-Power | 660 |
| Motor | 2 Stage, 6.6", Bypass, Tangential Discharge |
| Power Unit Voltage | ~ 110 - 120 v |
| Input Power | 1680 watt |
| Shipping Weight | yes |
| Max. Amps | 14.0 |
| Hertz | 60 Hz |
| Dust Intake | Dual |
