PRODUCT / Central Vacuum Power Units / MUA85E

MUA85E

Pinnacle Twin Motor ~240v Allegro Central Vacuum Power Unit












Allegro MUA85E Pinnacle  is a super - powerful unit primarily used in industrial and commercial application or for very large homes up to 20,000 sq. ft. (2.000m2)



UPC: 609207104094








Image title





Allegro's Eco-Line Green Powered models are designed for high efficiency performance to save on electricity and are rated to have twice the life of regular blower motors. It saves money and the environment

- Now that is eco-friendly!

Motor:

 Lamb powered, 2-Stage AMETEK® 8.4" single speed motor with tangential bypass and 10mm shaft and dual bearing system for extra structural rigidity
Air Watts:  1265 Air Watts of efficient cleaning power
Air Flow:  Air flow of 165 cubic feet per minute
Suction Power:  Excellent suction power of 210 inch H2O lift
Max Amps:  Save on energy costs with a maximum current of 15 Amps
Volts:  Compatible with standard ~220 - 240v service.
Input Power  3425 watts of powerful performance making cleaning that much easier!

 Image title

Construction: 14" width  x 43" height with a 8 gallon dirt pail. Made of all steel construction. 41lbs.
Filtration:  Self cleaning, no maintenance, patented Fibro-Tex Filtration SystemsThis permanent filtration system never needs to be replaced or washed.
Finish:  Primed with environmentally friendly electrostatic powder coat. Guaranteed for life against corrosion perferation.



Image title Image title Image title Image title





Acoustic Unit Technical Specifications

Frequently Asked Questions

 Image title

Qty.:
1,999.99 USD
1,599.99 USD
Add to cart

Technical characteristics

Main parametersModel - MUA85E
Cleaning Area20,000 sq. foot
Suction Power210 inch water lift
Air-Flow165 CFM
Air-Power1265 Air Watts
Motor2 Stage, 8.4", Bypass, Tangential Discharge
Power Unit Voltage~ 220 - 240 v
Input Power3425 watt
Hertz60 Hz
Dust IntakeDual
