10 mm shaft and bearing system
Model: 115334
Operating Voltage: ~110 - 120v
Fan System: 2 stage
Size: 7.2" (183 mm) diameter
Bearings: Double ball bearings
Tangential bypass discharge
Fan End Bracket: Aluminum
Commutator Bracket: Aluminum
Max Amp: 13.0
Max R.P.M.: 21,800
Cycle: 50/60 Hz
Suction (in. H20): 110.0
Air Flow (cfm): 102.7
Air- Watts: 384
Input Power (watt): 1500
Max. Efficiency: 31%
Typical motor performance at ~120 v, test data is corrected to standard conditions of 29.92 Hg, 68ยบ F.
Designed to handle clean, dry, filtered air only.
Click here for Ametek Lamb 115334 Technical Specifications / Bulletin
Main parameters | Model - 140230 |
---|---|
Suction Power | 110.0 inch water lift |
Air-Flow | 102.7 CFM |
Air-Power | 384 |
Motor | 2 Stage, 7.2", Bypass, Tangential Discharge |
Power Unit Voltage | ~ 110 - 120 v |
Input Power | 1500 watt |
Max. Amps | 13.0 |
